SHAKE SD300 – Advanced Digital MEMS Accelerometer for Structural Health Monitoring
SHAKE SD300 is a tri-axial digital MEMS accelerometer. SHAKE SD300 embeds a MEMS sensor, while SHAKE QD332 is equipped with quartz one. Both are designed for structural health diagnostics (SHD) and vibration monitoring. The IP67 waterproof enclosure allows it to be deployed in challenging outdoors. By advancing CPU capability, SHAKE SD300 is superior in processing Real-time Data Stream.
$2.495,00
10 in stock
OVERVIEW
Description
Smart. Durable. Engineered for Structural Intelligence.
The SHAKE SD300 is a high-performance tri-axial digital MEMS accelerometer designed for structural health diagnostics (SHD), vibration analysis, and seismic monitoring. Encased in a rugged IP67-rated waterproof housing, it operates reliably in both indoor and outdoor environments — even under the most demanding weather and field conditions.
Advanced Performance and Real-Time Data Streaming
Powered by an advanced CPU, the SHAKE SD300 delivers real-time data streaming, rapid signal processing, and exceptional precision in vibration measurement. Its integrated MEMS sensor ensures accurate detection of structural motion, while the SHAKE QD332 quartz-sensor variant offers even higher sensitivity for research-grade measurements.
Smart Networking and Seamless Integration
Multiple SHAKE SD300 units can be networked through the PX01 / CUBE data logger for continuous recording, synchronized monitoring, and automatic event forwarding. When paired with SanDAS software, users can visualize waveforms, perform detailed analytics, and review post-event data with ease.
The PX01 / CUBE’s built-in algorithms automatically compute structural stiffness, drift ratios, and safety indicators — empowering engineers to assess building and bridge integrity immediately after seismic events. Configuration is simple through the SHAKE SD300’s integrated web interface, offering a plug-and-play installation that reduces setup time and complexity.
Key Features
-
🌐 Built-in Web GUI for easy configuration and live monitoring
-
🏗️ Optimized for Building and Bridge Vibration Analysis
-
📊 Compatible with SanDAS Software for visualization and data analytics
-
⚡ Ethernet PoE Support for plug-and-play connectivity
-
⏱️ NTP-Based Precise Time Synchronization
-
💧 Rugged IP67 Waterproof Design for harsh outdoor deployment
Applications
-
Structural Health Monitoring (SHM)
-
Vibration and Modal Analysis
-
Seismic and Earthquake Response Studies
-
Bridge and Infrastructure Life-Cycle Assessment
-
Building Integrity Evaluation After Earthquakes
Additional information
| Weight | 1 lbs |
|---|---|
| Dimensions | 20 × 20 × 15 in |
Product Specification
| SHAKE SD300 | SHAKE QD332 | |
|---|---|---|
| Sensor Type | Tri-axial digital MEMS accelerometer | Tri-axial digital Quartz MEMS accelerometer |
| Measuring Range | ±2 g, ±4 g (factory configured) | ±2 g, ±4 g (factory configured) |
| Dynamic Range | 100 dB | 132 dB |
| Sample Rate | 100 SPS, 200 SPS, 500 SPS, 1000 SPS | 100 SPS, 200 SPS, 500 SPS, 1000 SPS |
| Self-Noise | 22.5 μg / √Hz | 0.5 μg / √Hz |
| Shock Resistance | 5000 g (0.1ms) | 1000 g (0.2 ms) |
| Digital Resolution | 24 bit | 24 bit |
| Communication | RJ-45 PoE | RJ-45 PoE |
| LED Display | Power, status, link | Power, status, link |
| Mount Mode | Horizontal / vertical (adjustable with PX01) | Horizontal / vertical (adjustable with PX01) |
| System Configuration | Via web interface | Via web interface |
| Time Synchronization | NTP (Network Time Protocol) | NTP (Network Time Protocol) |
| Power Supply | PoE (Power over Ethernet, 12VDC) | PoE (Power over Ethernet, 12VDC) |
| Power Consumption | ≦1 Watt | ≦1 Watt |
| Operating Temperature | -20°C to 70°C | -20°C to 70°C |
| Relative Humidity | 5% – 90% RH (Non-condensed) | 5% – 90% RH (Non-condensed) |
| Waterproof | IP67 | IP67 |
| Weight | 550 g | 660 g |
| Dimension (L x W x H) | 137 x 75 x 55 mm | 137 x 75 x 55 mm |
*All prices, features, and specifications are subject to change without prior notice.
