Palert – SEISMIC SWITCH AND EARTHQUAKE EARLY WARNING SENSOR
P-ALERT is an advanced earthquake P-wave alarm detector system. It uses embedded Pd technology developed by Prof. Yih-Min Wu from National Taiwan University who has published many articles on this subject. With over 1,000 sold in Taiwan alone, it has proven successful and is now supported by the Taiwanese Government. P-ALERT devices are installed in the USA, Turkey, New Zealand, Philippines, Solomon Islands, India, China, Mexico, and Japan. All Products in the P-ALERT range are independently lab calibrated and certified.
$2.500,00
OVERVIEW
Description
The Palert Network Accelerometer is a state-of-the-art seismic detection system designed for rapid and reliable earthquake warning. Developed in collaboration with Prof. Yih-Min Wu of National Taiwan University, this device utilizes advanced P-wave alarm technology and Pd-based detection, issuing alerts within just 3 seconds of detecting seismic activity.
Key Features
✔ Advanced Seismic Detection – Detects P-waves and triggers alarms within 3 seconds
✔ Multiple Trigger Algorithms – Supports Pd, PGA, and STA/LTA for enhanced precision
✔ Supports Both On-site and Regional EEWS – Versatile deployment for different warning systems
✔ IoT-Enabled – Seamless integration for real-time monitoring and data sharing
✔ Time Synchronization – Via Network Time Protocol (NTP) or a PC utility for accurate event timing
✔ 2 Digital Outputs (RELAY/DRY CONTACTS) – Ensures compatibility with external alarm systems
✔ Modbus Protocol Support – Facilitates industrial and automation applications
Applications
📌 Earthquake Early Warning System (EEWS) – Provides crucial seconds of warning before shaking intensifies
📌 Rapid Structural Health Diagnosis (RSHD) – Assesses structures immediately after an earthquake
📌 Industrial Disaster Prevention – Enhances safety in factories and high-risk facilities
📌 Earthquake Monitoring – Tracks seismic activity with high precision
📌 Structural Health Monitoring – Monitors building integrity over time
📌 Bridge Engineering – Supports infrastructure resilience and safety
With its cutting-edge technology, real-time capabilities, and versatile applications, the Palert Network Accelerometer is an essential tool for seismic safety, infrastructure protection, and industrial disaster prevention.
Additional information
Weight | 1 kg |
---|---|
Dimensions | 20 × 20 × 20 cm |
SPECIFICATIONS
- Measuring Method: Tri-axial MEMS Accelerometer
- Communication Interfaces: Ethernet, RS-232, RS-485 (Modbus protocol supported)
- Detection Algorithms: Pd, PGA, STA/LTA
- Power Consumption: 3.5W @ 12VDC
- Output Resolution: 16-bit
- Power Supply: 10 – 30 VDC
- Data Recording: NTP synchronization or PC utility
- Operating Temperature: -10°C to 60°C
- Frequency Response: 0.05 – 20 Hz (with 10Hz/20Hz digital filter)
- Weight: 0.5 kg
- Measuring Range: ±2 g
- Dimensions (W × L × H): 125 × 105 × 30 mm
Specifications, features, and pricing are subject to change without prior notice.
