LX-H45
CNC H-Beam & I-Beam Laser Cutting Machine for Structural Steel Profiles
Five-in-one profile cutting production line, high-precision machinery, photoelectric detection, three-dimensional five-axis RTCP function, intelligent software algorithm, integrating optical, mechanical, electrical and software
Fully automatic processing production line, automatic recognition of steel structure TEKLA digital model
Directly input parameters according to two-dimensional and three-dimensional paper drawings to generate three-dimensional models (SIP, IGS, etc.)
Cutting profiles: H steel/C type/L type/bevel pipe
Application industries: steel structure, shipbuilding, elevators, heavy industry, engineering machinery, pressure vessels and other market segments
OVERVIEW
Description

3D 5-axis cutting
It can cut H-beams, C-beams, L-beams, as well as large area carbon steel corner plates.

Super heavy profile processing
It can satisfy processing requirements such as hole cutting, cutting, and corner cutting.

Intelligent CNC system specifically designed for pipe cutting
The system features a visual operation screen, easy parameter adjustments, and a wide range of functions. It supports multi-level perforation, intelligent tool retraction, automatic edge detection, and intelligent nesting, among other customizable features.
Technical Data
| Model: | LX-H45 |
| Laser Power: | 6000-20000W |
| Cutting Diameter Of Round Tube: | Ø 50-450mm |
| Cutting Diameter Of Square Tube: | ▢50*50-450*450mm |
| Cutting Tube Length: | 9000-12000mm |
| Dimensions: | ≈20150*3450*3250mm |
| Weight: | ≈7.5 tons |
| Cutting Tube Type: | H-steel / C-type / L-type / bevel |
| Cutting Material: | stainless steel, carbon steel, aluminum,copper,iron,etc |
Cutting samples
