SUBMERSIBLE LEVEL SENSOR HPT604
Categories:
Level Sensors, Monitoring
The Submersible Water Level Sensor is a general purpose submersible hydrostatic level transmitter. It adopts imported high quality piezoresistive sensor, robust 316L stainless steel housing and a hydrometric cable with the ventilation tube make it reliable and cost effective solution for a wide variety of industrial level applications. It can keep working fine in liquids for more than ten years.
Description
ADVANTAGES
- 316SS all-welded stainless steel body and 316L stainless steel diaphragm
- Unique 8 pressure holes design
- IP68 full sealed plastic waterproof design
- Construction shock and erosion
- Optional lifetime lightning protection
APPLICATIONS
- Hydrostatic level measurement
- Water pressure level measurement
- Deep well and groundwater monitoring
- Sea water level measurement and control
- Borehole water level measurement
- Level measurement in pumping station
KEY FEATURES
HPT604 |
---|
Range: 0~0.5 M…500 M H2O optional 80m max for SDI-12 signal |
Output: 4-20mA,0-5V,1-5V,0-10V,0.5-4.5V,SDI-12,RS485 Modbus RTU… |
Power Supply: 7-30Vdc,8-30Vdc,13-30Vdc,5Vdc,12Vdc,3.5-36Vdc… |
Accuracy: 0.5%F.S standard, 0.25%F.S by customized |
Working temperature: -40℃~80℃(non-corrosive medium) |
Temp Compensation: 0°C~80°C |
Zero Temp. Drift: 0.2%FS/°C(≤100kPa); 0.1%FS/°C(>100kPa) |
FS Temp. Drift: 0.02%FS/°C(≤100kPa); 0.01%FS/°C(>100kPa) |
Electronic connection: Fixed cable and water proof IP68 |
Response time: ≤10 ms |
Cable: PE, PUR, FEP cables with vents |
Certificate: CE,RoHS |
