QL-TANTU40 – Isolation Belt Cutting & Firefighting Robot
Isolation belt opens up robot TOPSKY (Multi-functional Attachment + Fire Extinguishing System + PushingShovel + Detection of 12 Kinds of Gases + Graphica + + +
and Numerical Integrated Remote Controller+ High and Low Pressure Hydraulic Expansion Interface + Leakage Detection
OVERVIEW
Description
Product Features:
- ▲ Multifunctional: It has the functions of fire extinguishing, path opening and traction. It can not only create forest firebreaks, but also carry out fire extinguishing operations and pulling and dragging operations.
- ▲ High Crushing Capacity: The diameter of the crushed trees is > 100mm.
- ▲ High Tractive Force: The traction force of the whole machine (KN) > 23kN.
- ▲ High Mobility: The maximum driving speed is > 10km/h, and the climbing angle is 55°.
- ▲ Highly Integrated Detection: It can monitor the gas concentration in the surrounding dangerous environment. The number of gas types is > 6, and the number of environmental parameter types is > 2.
- ▲ High-quality Imaging: The number of cameras is > 3, and a 360° pan-tilt is installed. The remote controller can remotely display the 360° image around the robot.
- ▲ Modular Expansion System: An ultra-high pressure output interface is reserved, and it can be externally connected to expand tools such as a hydraulic disc saw, ultra-high pressure demolition tools, and a hydraulic generator.
Product Parameters:
1.The diameter of the crushable trees is > 100mm.
2. The engine power is > 30kW.
3. The fuel tank capacity is > 25L.
4.The hydraulic oil tank capacity is > 40L.
5. The speed is > 10km/h.
