QL – Biaxial Hydraulic Shake Table | 5-Ton Capacity | 2 m × 2 m | 50 Hz
The QL Biaxial Hydraulic Shake Table is a high-performance seismic and dynamic testing system designed for structural, civil, and earthquake engineering applications. Featuring a 5-ton payload capacity, 2 m × 2 m steel table, and biaxial motion up to 50 Hz, it delivers precise, repeatable, and high-energy simulation of real-world dynamic events.
OVERVIEW
Description
The QL – Biaxial Hydraulic Shake Table (5-Ton, 2 m × 2 m) is engineered for advanced structural dynamics, seismic qualification, and vibration testing. It is designed to replicate real earthquake ground motions and dynamic load conditions. Additionally, the system provides high acceleration, large stroke, and wide frequency bandwidth under full payload conditions.
The system supports ±1 g acceleration at full 5-ton payload, with a ±200 mm stroke and operational frequencies ranging from 0.01 to 50 Hz. Its robust servo-hydraulic actuators, precision motion control system, and advanced earthquake simulation software ensure accurate reproduction of recorded seismic data. In addition, these features enable custom waveform profiles.
Delivered as a complete turnkey solution, the shake table includes hydraulic power units, accumulators, control electronics, and software. It also comes with on-site installation, commissioning, and operator training. Because of this, it is ideal for universities, research institutes, testing laboratories, and industrial R&D centers requiring reliable and high-fidelity dynamic testing infrastructure.
Technical Specifications
-
Table Size: 2000 × 2000 mm
-
Payload Capacity: 5 Ton
-
Acceleration Capacity: ±1 g at full payload
-
Stroke: ±200 mm (400 mm total)
-
Maximum Velocity: 500 mm/s
-
Continuous Velocity: 150 mm/s at full payload
-
Frequency Range: 0.01 – 50 Hz
-
Control Axes: 2 (Biaxial)
-
Displacement Resolution: 1 micron
-
Hydraulic Pressure: Up to 250 bar
-
Power Requirement: 180 kW, 380/400 V AC
Control System & Software
-
2-axis digital motion controller (CONTROLBOX-2P)
-
16-bit closed-loop PID control
-
Control loop up to 4 kHz
-
Real-time force and displacement feedback
-
Earthquake simulation software with:
-
Import of real seismic records (ASCII / AT2)
-
Sine, sweep, triangle, square, and custom waveforms
-
FFT, SRS, filtering, and scaling tools
-
Real-time visualization and data analysis
-
Installation & Training
-
On-site installation and commissioning
-
System calibration and verification
-
Two engineers on site for 5 business days
-
Operator, safety, and maintenance training
-
Complete commissioning documentation
-
Ongoing technical support
