Multi-Point Liquid Level Meter
The Multi-Point Liquid Level Meter is a hydraulic static level meter that utilizes liquid pressure measurements to calculate liquid level height. With its compact structure, small footprint, high precision, and exceptional stability, this instrument is designed to meet the demands of diverse applications. The product features an RS-485 communication interface and comes equipped with host computer software, providing users with the flexibility to configure parameters such as range, filtering, and sampling rate. This adaptability makes it suitable for integration and development across various system requirements.
OVERVIEW
Description
Introduction
The Multi-Point Liquid Level Meter is a hydraulic static level meter that utilizes liquid pressure measurements to calculate liquid level height. With its compact structure, small footprint, high precision, and exceptional stability, this instrument is designed to meet the demands of diverse applications. The product features an RS-485 communication interface and comes equipped with host computer software, providing users with the flexibility to configure parameters such as range, filtering, and sampling rate. This adaptability makes it suitable for integration and development across various system requirements.
Applications
Measurement values between observation and reference points are read during settlement
Calculations based on these measurements provide the settlement height of the observation point
Key Features
- Customizable Measuring Range
- Low Power Consumption
- Aluminum Alloy Casing
- Waterproof
Best Suited
- Bridges
- Tunnels
- Buildings
- Pits
Product Specification
| Product Function | Vertical displacement (settlement) measurement |
|---|---|
| Power Consumption | Working current 18 mA |
| Installation Method | Screw fixing |
| Communication | RS-485 Modbus |
| Measurement Range | 1000 mm |
| Operating Temperature | -25 °C to 85 °C |
| Accuracy | 0.05% F.S. |
| Temperature Compensation | -20 °C to 70 °C |
| Resolution | 0.01 mm |
| Dimensions (LxWxH) | 68 x 68 x 47 mm |
| Power Supply | DC 5-12 V |
*All prices, features, and specifications are subject to change without prior notice.
