EQ206 PORTABLE NODE SEISMOGRAPH (WIFI, SINGLE COMPONENT)

The EQ206 Intelligent Node Seismograph is a compact, high-precision system for real-time seismic monitoring and subsurface investigations. With 32-bit ADC, GPS synchronization, mobile app control, and support for 100,000+ channels, it ensures reliable performance across geophysical and engineering applications.

$995,00

OVERVIEW

SPECIFICATIONS

FEATURES

FAQs

Data Sheet

Request a Demo

OVERVIEW

The EQ206 Intelligent Node Seismograph is an advanced seismic data acquisition system engineered for real-time monitoring and high-precision subsurface investigations. Equipped with cutting-edge technology and designed for seamless integration across diverse geophysical and engineering applications, it delivers exceptional reliability and performance in the field.

Practical Applications of EQ206:

✅ Engineering Exploration:

  • Detection of urban underground spaces and drainage pipelines
  • Identification of engineering cracks and roadbed anomalies
  • Surveys for hollowing zones and rock formation studies
  • Research on the depth, shape, and distribution of basal layers

✅ Resource Exploration:

  • Real-time monitoring of oil & gas fracturing, landslides, and road collapses
  • Imaging of oil and gas pressure cracking
  • CCUS carbon dioxide storage monitoring and imaging

✅ Structural Exploration:

  • Monitoring of karst formations, fault fracture zones, and collapse columns
  • Real-time monitoring of overburden thickness
  • Imaging of geological structures

✅ Real-Time Monitoring:

  • Deployment as mobile seismic monitoring stations
  • Long-term real-time monitoring of microseismic events
  • Real-time geological disaster warning systems

✅ Natural Activities:

  • Monitoring crustal and upper mantle plate activities
  • Strategic mineral exploration and geothermal energy monitoring
  • Dense array background noise imaging for scientific research

PRODUCT PHOTOS

EQ206_3
EQ206-Photoroom
EQ206_2
GN309_1-Photoroom
GN309_2-Photoroom
GN309_3-Photoroom
GN309_4-Photoroom
GN309_5-Photoroom
GN309_11-Photoroom
GN309_13-Photoroom
GN309_14-Photoroom

SPECIFICATIONS

Natural Frequency:

5 Hz

Sensitivity:

190 V/m/s

Bandwidth:

5s ~ 200 Hz

Dimensions:

107.5 mm x 107.5 mm x 125.5 mm (without cone)

Weight:

< 1.3 kg (with battery, without cone)

Sensor Channels:

Single component

Dynamic Range:

123 db

Power:

Built-in battery for up to 30 days of operation (24 hours)

Operation Temperature:

-40 to 85 degree Celcius

Signal-to-Noise Ratio:

High SNR to ensure clear and accurate data acquisition

Build:

Durable construction for use in harsh environments

Surface Wave Techniques:

Compatible for MASW and ESPAC

FEATURES

Ultra-Precision ADC: 32-bit resolution ensures low-noise, accurate data.
GPS & Precision Clock: Long-term synchronization for reliable accuracy.
Compact Design: Lightweight, built-in detector for easy deployment.
Mobile App Control: Real-time monitoring and deployment tracking.
Source Compatibility: Supports both active and natural sources.
Scalable System: Handles over 100,000 channels.
Efficient Charging: 32-channel cabinet enables simultaneous charging and export.
High Reliability: Supports 10,000+ operations economically.
Advanced Software: Includes 2D/3D analysis tools.
Data Format Support: SEG-2, SEG-Y, SEG-D, SAC, Mini SEED compatible.

FAQs

How long time can EQ206 detect with built-in battery?
It can detect more than 20 days with built-in battery.
Can we arrange samples for clients to test, will it charge?
Yes, we can arrange renting samples, cost including rent payable, freight and deposit (will return back to you after the device returned).
Is the charging box and data collection the same device？
Yes, it is. Our charging, data recovery, using the same 32-slot charging&data harvesting unit simultaneously.
What output data formats are provided?
SEG-2, SEG-Y, SEG-D, SAC, Mini SEED
Can it stream data?
Yes, thanks to its embedded seedlink server.
What are the ideal applications for the EQ206 ?
The EQ206 is ideal for MASW measurements, microseismic monitoring, and volcano monitoring, thanks to its portability, long battery life, and advanced data acquisition capabilities.
