CNC 4th Rotary Axis Router suits column engraving and flat material carving and cutting. Besides the side position of rotary device, you could also mount smaller size rotary device on the working table for column engraving. This function could be used in the industry of stair parts, such as turned and box newel posts, corbel, handrail, chair jamb etc.
OVERVIEW
Description
QuakeLogic is an authorized distributor of OMNICNC
CNC 4th Rotary Axis Router
CNC 4th Rotary Axis Router suits column engraving and flat material carving and cutting. Besides the side position of rotary device, you could also mount smaller size rotary device on the working table for column engraving. This function could be used in the industry of stair parts, such as turned and box newel posts, corbel, handrail, chair jamb etc.
ROTARY DEVICE / 4th AXIS
With this 4th axis roatary attachment, you could also work on cylindrical material, besides cutting flat material.
TABLE ATTACHMENT ROTARY DEVICE
If you work on large diamter of cylindrical material, like 20-30cm diameter cylinder. We custom design this rotary device, with cylinder support for holding up it.
Parameters
| X,Y-Axis Travel | 1300*2500 ,1500*3000, 2000*3000mm |
| Z-Axis Travel | 200mm or others |
| Spindle Power | 3kw watercooling 24000rpm or higher power; HSD3kw aircooling 18000rpm or higher power |
| Repeatability | +/- 0.05mm |
| Max. Rapid Travel Speed | 15m/min-40m/min |
| Drive System X and Y axis | Rack and Pinion, rail linear bearing |
| Drive System Z axis | Lead Screw, rail linear bearing |
| Standard Work Surface | aluminium T-Plate Extrusion Combined Bakelite Vacuum Table |
| Motor | Stepper/Servo |
| Spindle Protection Device | digital spindle temperature monitor (not fitted for air-cooling spindle) |
| Working Voltage | AC380V/50HZ, 3PH; 220V/60Hz,3PH; AC440V/50HZ, 3PH |
| Command Language | G Code&M Code |
| Collet | ER20 or ER25 or ER32 |
| Operating System | DSP Handheld Controller/ NC studio/ Syntec |
| Rotary Device Diameter | 70-500mm |
