Description

The QL-SeismoSense Acoustic Emission Monitoring System is an advanced solution for real-time structural and seismic monitoring. It helps detect material fatigue, structural stress, and micro-seismic activity at an early stage. As a result, operators can respond faster and reduce risk in critical environments.

This system is built for infrastructure, industrial facilities, and geotechnical applications. It combines multi-channel acoustic emission data acquisition with high-speed sampling and FPGA-based signal processing. Therefore, it delivers accurate and continuous monitoring in demanding conditions.

QL-SeismoSense supports 4, 8, or 16 channels, which makes it suitable for different project sizes. In addition, it offers sampling performance up to 5 MS/s at 16-bit for reliable signal capture and analysis.

The system also includes integrated GPS synchronization for precise time alignment. Moreover, Ethernet and Wi-Fi connectivity allow remote access through a web-based monitoring interface. This improves usability and simplifies system management in the field.

Its modular MASTER/SLAVE architecture gives users more flexibility during deployment. Furthermore, remote firmware updates help reduce maintenance effort and downtime.

The QL-SeismoSense Monitoring System is ideal for a wide range of uses, including:

• Structural health monitoring
• Post-seismic damage analysis
• Quarry and mining monitoring
• Infrastructure safety systems
• Industrial equipment monitoring

The device is designed for harsh environments. It features an IP68-rated anodized aluminum enclosure and operates in temperatures from -40°C to +85°C. Because of this, it provides stable long-term performance in challenging field conditions
